Name: Sinotruk HOWO 8 CBM Capacity Oil Tank Truck with 4x2 Drive Type and Euro III Emission Standard
Brand: SINOTRUK INTERNATIONAL CO., LTD.
SKU: ZZ1127G4215C1
Price: 33,750.00 USD
Availability: InStock

홈 제품 소개 석유 탱크 트럭

Sinotruk HOWO 8 CBM Capacity Oil Tank Truck with 4x2 Drive Type and Euro III Emission Standard

제품 상세 정보:

원래 장소:	중국
브랜드 이름:	SINOTRUK
인증:	ISO/3C/BV/IFA/SGS
모델 번호:	ZZ1127G4215C1

결제 및 배송 조건:

최소 주문 수량:	1개 단위
가격:	협상 가능
포장 세부 사항:	왁싱
배달 시간:	35 일
지불 조건:	티/티
공급 능력:	한 달에 3000 단위

접촉

상세 제품 설명

차량 배기가스 기준:

유로 III

드라이브 유형:

4 x 2

탱크 유형:

기름, 연료

모델:

ZZ1127G4215C1

강조하다:

8 CBM Capacity Oil Tank Truck

4x2 Drive Type Oil Tank Truck

Euro III Emission Standard Oil Tank Truck

Sinotruk HOWO 4*2 Oil Tanker - 8 Cubic Meter Capacity

The Sinotruk HOWO 8 CBM tank truck is designed for efficient oil transport with 4*2 left-hand drive configuration and 140HP engine. These versatile mobile refueling vehicles serve multiple applications including fuel distribution, pump operations, and various oil loading/discharge functions.

Key Components

The specialized tank system includes the oil tank, PTO (Power Take-Off), drive shaft, gear pump, and comprehensive piping system. The pipeline configuration features one oil pump, three and four channel ball valves, and two-way valves with filter tube integration.

Technical Specifications

Chassis Model	ZZ1127G4215C1
Drive Type	4*2
Engine	YC4E140, 140HP, Euro Standard
Cabin	2080 lengthened cab with sleeper, air-conditioner, and two new-style seats
Transmission	DC6J48TC (6 forwards & 1 reverse)
Front Axle	3.2 Tons
Driving Axle	8.2 Tons
Clutch	Hydraulically operating with air assistance
Rim/Tire	8.25-20, 9.00R20
Wheel Base	4200 mm
Tank Capacity	8 CBM
Tank Thickness	3mm with 2 cabins
Basic Setup	Gear oil pump, flow meter, flash hider, fire extinguisher
Overall Dimension	712824623175 mm
Curb Weight	6300 Kg
Gross Weight	12490 Kg
Maximum Speed	95 km/h
Available Colors	White, red, green, golden and more

Primary Applications

This oil tank truck is specifically designed for transporting petroleum derivatives including gasoline, diesel oil, lubricating oil, and coal tar oil. It serves critical roles in transportation and storage operations across various industrial sectors.

Competitive Advantages

Advanced butt welding technology with high-pressure gas leak detection for superior tank strength and vehicle stability
Shot blasting pretreatment process with advanced rust prevention and durable paint technology
Specialized configurations for petroleum, chemical, food transport, thermal insulation, dangerous goods, and asphalt applications
External sandblasting treatment with internal anti-corrosion protection and polyurethane exterior finish
Optional front and rear high-pressure spray systems with 360-degree rotation and 150-degree tilt capability
Comprehensive model range to meet diverse operational requirements
Integration of world-class technology components for enhanced reliability
Strong technical support and manufacturing expertise ensuring high-quality production
Competitive pricing with exceptional cost-effectiveness
Fast and efficient spare parts supply network
Accurate production scheduling for timely delivery
Professional import/export trade procedures for efficient customs clearance

This versatile oil tanker can be configured for various specialized applications including optional small flow pumps for garden and agricultural spraying operations.
